Overview

vCloudPoint Zero Client Computing

vCloudPoint zero clients, combined with vMatrix software, provides an innovative way of desktop computing — Sharing Computing, which delivers the same PC experience desktops to users at a fraction of the cost of a typical PC solution, while still offering a variety of benefits over PCs

Extending 1 PC to 100 workstations

The vCloudPoint zero client is a network computer terminal that effectively allows multiple users to simultaneously share the untapped resources of a PC desktop while still providing users with the same PC experience.

Run vCloudPoint Thin Client thin client 30 10809 Videos on an 1 Server

It is not just a computer terminal. But a new way to deliver desktops.

vCloudPoint Thin Client | Zero thin Client

Thin Client Zero thin Client

vCloudPoint zero client is also referred to as ultra thin client, because it contains no moving parts but centralizes all processing and storage to just what is running on the host. As a result, it requires no local driver to install, no patch management, and no local operating system licensing fees or updates. The device consumes very little power and is tamper-resistant and completely incapable of storing any data locally, providing a more secure endpoint.

Replace desktops with vCloudPoint zero clients, Save:

  • Share one PC with up to 99 users
  • 70% in capital cost.
  • 95% in power consumption.
  • 95% in maintenance cost.
  • 90% in future up-gradation.

Getting it ready is easy as 123!

1

Install vMatrix Software

2

Create User Accounts

3

Connect to Start

vMatrix Server Manager Software

The vMatrix Server Manager software, running on the host PC, enhances the overall functionality and usability of the sharing system by offering connection brokering, graphic acceleration, audio & USB redirection, centralized management. IT Administrators can configure, monitor and manage the endpoint devices and users centrally and simply at the server side through the front-end console.

The functions performed by vMatrix Server Manager software include:

  • Giving the administrator complete visibility into the OS, CPU, memory, storage, networking and other critical elements of the host computer;
  • Creating and managing user accounts & password;
  • Authorizing users to access specific desktop session;
  • Discovering vCloudPoint zero clients and USB peripherals;
  • Monitoring and controlling end user desktops;
  • Configuring user USB, audio, resolution, video, etc;
  • Broadcasting the administrator’s desktop to the end users;
  • Controlling privacy and visibility of disk partitions to users;
  • Providing a communication path for administrators & users through the integrated Chatting Room;
  • Keeping down user and administration behavior;

Dynamic Desktop Protocol (DDP)

vCloudPoint zero clients utilize its innovative Dynamic Desktop Protocol for remote desktop display. This protocol consists of Graphic Acceleration, Virtual Audio and USB Redirection for delivering a full PC experience.

Unlike other remote display protocols, such as the Window built-in RDP (+ RemoteFX), SPICE for open source KVM virtualization platforms, and the various protocols derived from them, the DDP is completely original from vCloudPoint, and with lots of optimization. In terms of image transmission and operation processing, DDP Graphic Acceleration module provides efficient image compression, transmission and coding, to ensure PC-like smoothness and responsiveness; additionally it reduces image compression loss to improve pixel resolution and color rendition as well as reducing network bandwidth and host resource consumption to optimize multi-process processing capabilities so that experience of multi-user scenarios can be the same as that of single user. In terms of audio transmission, the DDP virtual audio driver supports stable I / O bi-directional audio, and uses high code rates, bit rates, and sample rates to deliver high-definition audio quality while guaranteeing millisecond-level delayed audio transmission. In terms of the USB device support, DDP USB device re-director achieve stable USB device support by extending the physical USB bus with virtual USB bus. Remote USB device can be recognized at a few seconds when connected, without requiring a dedicated client driver installed. In multi user environment, storage device isolation is also enabled by users for data security; and some restrictions or side problems of USB redirection that may be encountered in other competitive solutions are eliminated with our solution.

Full HD Video

  • Real full HD local or online video
  • Any media format, any media player
  • 30fps, smooth in 1920*1080 resolution
  • 30 simultaneous 1080p videos on an i7 host

High Quality Audio

  • 16 bits 44.1/48 KHz high quality
  • Play and record in all supported OSs
  • Fully synchronized, only 0.1-0.2 sec delay
  • No configuration, plug and play

Broad USB Devices

  • Support a broad range of peripherals
  • No client driver required
  • Plug and play, works any time
  • No side issues like multiple printer copies or memory devices visible to everyone

Benefits

vCloudPoint Zero Client Computing

vCloudPoint zero clients, combined with vMatrix software, provides an innovative way of desktop computing — Sharing Computing, which delivers the same PC experience desktops to users at a fraction of the cost of a typical PC solution, while still offering a variety of benefits over PCs

An Innovative Way of Desktop Computing

Discover the benefits from replacing desktops with vCloudPoint Zero Clients

Reducing costs

  • Reducing initial acquisition costs— The initial acquisition costs are saved when replacing PCs with vCloudPoint zero clients which cost less than half the price of entry-level PCs.
  • Better leverage of IT budgets — Sharing resources on a centralized PC improves leverage of hardware upgrade budgets and software licensing.
  • Minimizing endpoint maintenance — With no failure -prone moving parts, repairs on the zero clients are rare and your maintenance costs are minimized to just on the shared computer.
  • Greater energy saving— Compare to the 110 watts or more by a typical PC, the vCloudPoint zero clients consume only 5 watts and produce much less heat, providing at least an 80% savings in energy consumption and air conditioning over PCs.
  • Longer desktop refresh cycles— Lack of moving parts improves life spans in harsh environments like restaurants, public spaces, warehousing and manufacturing. The obsolescence-free feature also proves longer desktop refresh cycles, saving both refresh budgets and cutting the time for the refresh from weeks to hours.
  • Easy provisioning— Deploying hundreds of workstations can be a few hours compared to days or weeks with PCs. Install the vMatrix Server software on the shared PC, add multiple users, plug in Ethernet cable, mouse, keyboard, and monitor, and users are ready to work. A new workstation can be setup in seconds.
  • Centralized management.— There is nothing for IT to configure, manage, or update at the endpoint. All installations, patches & updates are done on a single host. One IT staff can handle 5 times as many devices and users compared to PCs.
  • Remote technical support — IT and support staff can provide support or fix problems right from their desks through monitoring and controlling over user desktops, eliminating the costs and delays of having to travel to remote user locations.

Increasing productivity

Improving efficiency

  • Reducing unplanned downtime — With no failure-prone parts and desktop-related problems unplanned endpoint downtime is greatly reduced. Even when turn faulty, the vCloudPoint zero client can be placed, helping the user back to work in seconds.
  • Rapid roaming from any client— No time is wasted on moving a heavy laptop or rebooting the system. With a simple log-off and then log-in from any vCloudPoint zero client, the user’s back at his desktop with all open applications and files still in place.
  • Enabling file sharing — With some disks configured visible to all, users can share and store files easily on these public disks without the need to copy or transfer between desktops.
  • Eliminating virus infection— With no resident OS or storage capable of running software, the vCloudPoint zero client provides a completely secure endpoint that is immune to viruses and other malware.
  • Security policies and monitoring— vMatrix allows IT staff to apply security policies, monitor, and remotely disable any end user from logging in or lock-down locally connected USB peripherals, preventing users from copying confidential data to removable storage.
  • No risk of data lost— Since the vCloudPoint zero clients cannot store any data locally, users are free of worrying about data loss stemming from hardware failure or laptop/PC theft.

Enhancing security

Protecting Environment

  • Freeing desktop footprint— The vCloudPoint zero client is only a cellphone size and can be mounted on the back of the monitor to save valuable space on the desktop.
  • No Noise on working— Without any storage and fan, the vCloudPoint zero client makes no noise when running.
  • Less heat and e-waste— Consuming much less energy meaning the vCloudPoint zero client produces much less heat and e-waste when compared to standard PCs.

Highlights

vCloudPoint Zero Client Computing

vCloudPoint zero clients, combined with vMatrix software, provides an innovative way of desktop computing — Sharing Computing, which delivers the same PC experience desktops to users at a fraction of the cost of a typical PC solution, while still offering a variety of benefits over PCs

Power Up Your Desktop Computing

The vCloudPoint solution comes from a combination of insight, innovation, and deep knowledge of computing technologies that no other solution can match.



Rich Multimedia Support

Traditional zero clients basically use RDP enhanced technology or client-embedded media player for video acceleration, which results in restrictions of limited media format support, web-embedded video not supported, a few number of concurrent video users per host and still the display quality largely sacrificed to far behind that of the original 720/1080P file that they claimed to support.

Powered by the vCloudPoint’s innovative DDP (Dynamic Desktop Protocol), users will experience real PC-quality videos scaled up to 1920×1080 resolution at full frame rates without excessive host-side processing or requiring a thin or zero client with media player and codec support. The video content can be any present and future format and either played through standalone media players or embedded into web pages.

Reliable & High Quality Audio

The Windows audio redirection used by the most zero or thin clients was generally not designed specifically for the sharing scenario, leading to the frequent issues of audio incompatibility or unreliability in remote desktop.

Instead of using Windows built-in audio for remote desktops, vCloudPoint zero clients use its specific virtual audio technology which enables reliable audio playing and recording in any Windows systems, without hidden limitations or additional configurations. To further achieve high quality and synchronized audio, vCloudPoint’s virtual audio technology reduces transfer delay to 0.1~ 0.2 second- 1/20 of that by RDP and uses sample rate at 44.1KHz which is equivalent to CD-quality and 48KHz which is used in professional music production, providing you the best audio experience no matter if you are watching a big movie, providing customer service in a call center, or audio-teaching in a language lab.

Broad USB Peripherals Support

Peripheral support on Windows remote desktop is commonly known to be weak. Endpoint embedded operating systems often require customized client drivers, greatly reducing the range of peripherals that are natively compatible and driving up deployment timelines and ongoing support costs. Even for those supported peripherals, they still have various issues such as device often not detected by the system if users didn’t strictly plug them in as required, a printer copy generated on each time the printer is plugged into the system, and many more.

vCloudPoint zero clients use its transparent USB technology that peripherals never require specialized client drivers to work – just a native Windows driver is required. vCloudPoint zero clients support a wide range of USB devices including memory device, headphone, printer (both single and multiple functional), scanner, touch screen, U key, card reader, and USB converters. These USB devices are compatible and reliable with all Windows systems that whenever and however you attach them to the zero clients, they are fully functional.

Secure User Isolation

Sharing is the most efficient and cost-saving way of computing, but we didn’t want just anyone to have access to the others’ personal data. That’s why we provide the administrator the choice to configure storage visibility to users, achieving user isolation and privacy protection.

The vMatrix Server software overcomes the privacy weakness of traditional sharing solution by putting each user session into a self-container. Each vCloudPoint user has his/her private workspace which cannot be accessed by other users while the rest disk partitions still can be configured visible or invisible to the users. This brings high security to every user with a self-own workspace as well as increased efficiency with a shared center.

Customizable User Experience

Just as the desktop virtualization expert Brian Madden said “low bandwidth, good user experience, low CPU, pick any two”, in remote desktop technology, users cannot have their cake and eat it. With other solutions, users are often left no choice or one-time choice among smoothness, display quality and number of concurrent video users. While in reality, users’ requirement for user experience varies in time and circumstances.

vCloudPoint’ s DDP technology allows administrators to customize user experience to meet requirements in different scenarios. Administrator can use the default “optimum” setting for delivering the richest computing experience to users, and switch to the “balanced” setting for reducing the consumption of host resources while enabling smooth HD video playback, or the “economic” setting for maximizing the number of working users. Administrators can still go down in detail to configure for each vCloudPoint zero client user, such as USB, audio, resolution, video, etc.By transferring only dynamic pixels, vCloudPoint’s DDP technology can effectively reduce the consumption of CPU resources and network bandwidth while still offering the best display quality to 95%-96% as that of PCs.

Useful Auxiliary Tools

The vMatrix Management Center provides the IT administrators a user-friendly interface with increased manageability. Besides the general user and desktop management, IT administrators can broadcast his desktop to the endpoint users, communicate with them through the internal Chatting Tool, provide support through monitoring and control over the endpoint desktop, and and still more future tools and functions are avaliable with free updates.

Simple to Set Up and Use

We put a lot of effort to make sure that working with the vCloudPoint zero clients will be a great fun for you, as it is for us. You will love the way how easily things can be done, just in few clicks. We tried to do everything as much intuitive as it only can be. Easy software installation, zero configuration and plug-and-play devices – all to make your work easier.

There is only the server suite software to run on the host computer for setting up the system The whole installation process is just a few next-and-finish steps plus user creation. Whether it is a 100 or 1000 seats deployment, it can be completed in just a few minutes. The vCloudPoint zero client provides a hands-on working experience to users. Its login interface allows discovery and inventory of in-LAN hosts, and automatic login. Only a click-on, they are ready to work.

Comparisons

vCloudPoint Zero Client Computing

vCloudPoint zero clients, combined with vMatrix software, provides an innovative way of desktop computing — Sharing Computing, which delivers the same PC experience desktops to users at a fraction of the cost of a typical PC solution, while still offering a variety of benefits over PCs

vCloudPoint Comparison

S100

Classic Model

  • Size of a 4.7-inch iPhone
  • VGA Video Output
  • 10/100 Mbps Ethernet
  • With mounting bracket, without anti-theft gadget

V1

HD Display Model

  • Size of a fist
  • VGA & HDMI Video Output
  • 10/100/1000 Mbps Ethernet
  • With mounting bracket and anti-theft gadget

vCloudPoint Specifications

The following Specializations are based on vMatirx Server Manager 2.1.1, and device firmware 2.0.2.18;
Specializations may vary depending on the software versions.



S100 V1
Appearance Size 124(W)x75(D)x26(H) mm 93(W)x90(D)x18(H) mm
Net Weight 107g 150g
Color Matte black Diamond black & moon sliver
Connections Video 1×VGA 1×HDMI,1×VGA
USB 4×USB 2.0 4×USB 2.0
Network 1×RJ45 1×RJ45
Audio 1× 3.5mm audio input,
1× 3.5mm audio output
1× 3.5mm audio input,
1× 3.5mm audio output
Power 1×5V DC 1×5V DC
Switch 1×power/reset switch 1×power/reset switch
Anti-theft Gadget No Yes
Power Consumption Standby: 0.2w; Working:
5W (independent of external USB devices)
Standby: 0.2w; Working:
5W (independent of external USB devices)
Display Support VGA HDMI / VGA
Resolution Standard (32 bits @ 60Hz) 640×480,800×600,1024×768,1280×1024,1600×1200
Wide (32 bits @ 60Hz) 1360×768,1366×768,1440×900,1600×900,1680×1050,1920×1080
Configuration Methods Host side & Client side Host side & Client side
Audio Support HQ16 bits, 44.1Khz/ 48Khz,input and output through 3.5mm jacks or USB ports
Video Support Full HD 1080p for all media formats
(Server-side rendering for local and web-embedded videos on most media players;
Client-side rendering for local videos on VLC player 2.1.5 or newer versions)
USB Devices Support Storage Devices, USB Hubs, Single, Multi-functional & Dot Matrix Printers,Smart Card Reader, Office &
POS Scanners, Single Touch Screens, Ukeys, Parallel to USB Convertors, etc; An external power supply
may be required for devices working on large voltage. View Test USB devices
Networking Wired 10/100 Mbps Ethernet (RJ45) 10/100/1000 Mbps Ethernet (RJ45)
WIFI optional external WIFI antenna
at additional cost: 802.11b/g/n
optional external WIFI antenna
at additional cost: 802.11b/g/n
Maximum number
of users per shared host
vMatrix Server Manager permits up to 99 users per shared host. Actual number of supported users
depends on the host configuration and the type of applications used. View Host Configuration Guide
Internal hardware All solid-state design. No moving parts, no fans, no local user storage.
Data Security No local data storage on device. USB data access controlled by user policy.
Reliability(MTBF) >100,000 hours
Environmental 0 to 40 degrees Celsius 10 to 85% relative humidity (non-condensing) No moving parts permits use in
high dust / particulate / vibration environments.
Certifications FCC Class A&B, CE, CCC, RoHS compliant, BIS, NOM, ISO 9001:2015, ISO 14001:2015
Software System Microsoft Windows XP SP3 Pro 32bits, 7, 8 ,8.1 & 10 (excluding Starter, Home Basic and Insider editions),
Server 2003 32 bits, 2008R2, 2012, 2012R2, 2016, Multipoint Server 2011, 2012
Included Software vMatrix Server Manager with Dynamic Desktop Protocol (DDP)
Optional Software vMatrix Classroom Control at additional cost
